Instrumentation
19
%
*
[IS07830(R)05/96]
Battery Voltage Gauge (Voltmeter)
*
[IS07900(R)04/96]
This gauge shows you the battery voltage when the ignition key
is in the ON position.
*
[IS08000(R)04/96]
If the battery is operating under cold weather conditions, the
pointer may indicate in the upper range of the NORMAL band
while the battery is charging. If you are running electrical
accessories with the engine off or idling at a low speed, or the
battery is not fully charged, the pointer may move toward the
lower end of the NORMAL band.
*
[IS08100(R)04/96]
If it stays outside the NORMAL band, have your vehicle’s
electrical system checked as soon as it is safely possible.
[IS08200(R)01/96]
7-1/2 pica art:0020051-F
Battery voltage gauge — mechanical cluster
[IS08300(R)01/96]
7-1/2 pica art:0020539-H
Battery voltage gauge — mechanical cluster with tachometer
