230

[ER13900(R)01/96]

To remove the spare tire:

[ER14000(R)01/96] 1.Usethehexportionofthelugnutwrenchtoremovethe

boltthatfastensthehingetothechannel.

[ER14100(R)01/96] 2.Swingthehingeawayandlowerthechannel.

[ER14200(R)01/96] 3.Unscrewtheretainingboltusingthetaperedendofthelug

nutwrenchthroughtheeyeofthebolt.

[ER14300(R)01/96] 4.Slidethesparetireout.

[ER14400(R)04/96]

To stow spare tire:

[ER14500(R)01/96] 1.Positionsparetire,valvestemdown,soitisbalancedonthe

support.

[ER14600(R)01/96] 2.Replaceandtightenretainingboltusingthetaperedendof

thelugnutwrenchthroughtheeyeofthebolt.

[ER14700(R)01/96] 3.Raisechanneltohingeandlineupthebolthole.

[ER14800(R)01/96] 4.Installboltandtightenwiththewrench.

[ER15100(R)01/96]

WARNING

Makesurethesparetireandjackingequipmentare

stowedandsecuredintheproperstoragelocation.

[ER15200(R)03/96]

PreparingtoChangetheTire

[ER15250(R)01/96]

NOTE:Toliftyourvehiclebyotherthanthefrontorrear

jackingpoints,besuretouseonlyhoistadapterswith

awidecontactsurface.

[ER15300(R)01/96] 1.Makesurethatyourvehiclewillnotmoveorroll.Ifyou

haveanautomatictransmission,putthegearshiftinPark.If

youhaveamanualtransmission,putthegearshiftin

Reverse.Settheparkingbrakeandblockthewheelthatis

diagonallyoppositethetirethatyouarechanging.

[ER15335(R)01/96]

NOTE:MakesuretheignitionisintheOFFposition.

File:10unerr.ex

Update:Thu Mar 20 08:56:46 1997
