Maintenance and Care
301
[MC47415(R)01/96]
Tail Lamp Bulb
[MC47420(R)01/96]
Removing the tail lamp bulb
[MC47425(R)01/96] 1. Remove the four (4) screws retaining rear lamp to vehicle.
[MC47430(R)01/96] 2. Remove rear lamp.
[MC47435(R)01/96] 3. Remove socket from lamp.
[MC47440(R)01/96] 4. Remove bulb from socket.
[MC47465(R)01/96]
Installing the tail lamp bulb
[MC47470(R)01/96] 1. Install tail lamp bulb in socket.
[MC47475(R)01/96] 2. Install socket to lamp.
[MC47480(R)01/96] 3. Install lamp to vehicle.
[MC47485(R)01/96] 4. Install four (4) lamp retaining screws.
File:11unmcr.ex
Update:Thu Mar 20 08:58:43 1997
