96
*
[CF80520(R)01/96]
NOTE: The operating range of the remote entry system can
also be affected by weather conditions (such as very
cold temperatures) or structures around the vehicle
(buildings, other vehicles, radio and TV towers, etc.).
Typical operating range will allow you to be up to 33
feet (10 meters) away from your vehicle.
[CF80530(R)01/96]
7-1/2 pica art:0021161-A
Opening the remote transmitter
*
[CF80540(R)05/96]
The remote can be snapped apart to replace the batteries by
twisting a thin coin between the two halves of the remote. DO
NOT TAKE THE FRONT PART OF THE REMOTE APART.
When installing the new batteries, be sure to place the positive
(+) side down as marked. Snap the two halves back together.
[CF80550(R)01/96]
7-1/2 pica art:0021162-A
Replacing the batteries
File:05uncfr.ex
Update:Thu Mar 20 08:51:14 1997
