Fuse/Relay
Location
Fuse Amp
Rating
Circuits
protected
28 15A** Heated oxygen
sensors,
canister vent
29 - N/A
30 - N/A
31 - N/A
32 - N/A
33 - N/A
*Maxi fuses. **Mini fuses
Always disconnect the battery before
servicing high current fuses.
Always replace the cover to the Power
Distribution Box before reconnecting the
battery or refilling fluid reservoirs.
Relays
Relays are located in
the power distribution
box and should be
replaced by qualified
technicians.
