Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
8 10A Low beam headlamps (right)
9 15A Interior lights, Cargo lamps
10 15A Switch illumination, Puddle lamps
11 10A All wheel drive (AWD) module
12 7.5A Passive entry/passive start
(PEPS) module
13 5A Memory seats, Mirrors, Keypad,
PEPS receiver, Driver’s door
module
14 10A Navigation display, Memory seat,
SYNC威, Center information
display, GPS, Driver seat
15 10A Climate control
16 15A Electronic finish panel, Ambient
lighting
17 20A Trunk release, Moon roof, Smart
windows, Lock/unlock
18 20A Rear heated seats
19 25A Audio amplifier
20 15A Diagnostic connector (OBDII),
Adjustable pedal motor
21 15A Daytime running lamps (DRL)
control
22 15A Park lamps, License plate lamps,
Auxiliary lamps
23 15A High beam headlamps
24 20A Horn
25 10A Demand lighting (battery saver)
26 10A Instrument panel cluster,
Heads-up display
Roadside Emergencies
289
2010 Taurus (500)
Owners Guide, 3rd Printing
USA (fus)
