Fuse/Relay
Location
Fuse Amp
Rating
Power Circuits
26 10A* Backup relay
27 25A* Fuel pump
28 80A** Engine cooling fan
29 — Not used
30 — Not used
31 — Not used
32 30A** Driver seat
33 30A** Passive entry/passive start
(PEPS)
34 — Not used
35 40A** Front heater blower
36 20A* Passenger compartment fuse
panel run/start
37 10A* PCM relay
38 5A* Delayed accessory
39 Diode Fuel diode (iVCT only)
40 Diode One-touch integrated start (OTIS)
diode
41 G8VA relay A/C clutch
42 G8VA relay Fuel pump
43 G8VA relay Backup lamps
44 — Not used
45 — Not used
46 15A* Vehicle power 2 (PCM), Vehicle
power 3 (PCM)
47 20A* Vehicle power 1 (PCM)
48 20A* Vehicle power 4 (ignition coils)
49 15A* Heated mirrors
50 Half ISO relay Blower motor relay
51 Half ISO relay High-mount brake lamp w/ ACCM
relay
52 Half ISO relay Starter relay
Roadside Emergencies
293
2010 Taurus (500)
Owners Guide, 3rd Printing
USA (fus)
