Ford Transit Connect - Page 170

Circuits protectedFuse RatingFuse
Blower motor
40A
**
F10
Rear floor console auxiliary power point
20A
**
F11
Cargo area auxiliary power point (van only, vehicles
with Start/Stop)
Powertrain control module
30A
**
F12
Starter relay
30A
**
F13
Heated windshield (right-hand)
40A
**
F14
Cargo area auxiliary power point (van only, vehicles
without Start/Stop)
20A
**
F15
Luggage compartment auxiliary power point
(Tourneo, vehicles without Start/Stop)
Heated windshield (left-hand)
40A
**
F16
Floor console auxiliary power point
20A
**
F17
Not used-F18
Anti-lock brake system
5A
*
F19
Stability Control
Horn
15A
*
F20
Stop lamp switch
5A
*
F21
Battery monitor system (1.6 GTDI engine only)
15A
*
F22
Power supply voltage (powertrain control module
2.5 L engine only)
10A
Relay coils
5A
*
F23
Not used-F24
Power mirrors (without door control unit)10AF25
Engine control relay coil feed (2.5 L engine only)
5A
*
F26
Air conditioning clutch
15A
*
F27
Rear power window (without door control unit)
25A
*
F28
167
Tourneo Connect/Transit Connect (CHC) Canada/United States of America
Fuses
