Ford U137 Excursion 2005 - Page 204

Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
103 50A** Ignition switch (gasoline engine
only), FICM power (Diesel engine
only)
104 40A** Heated backlight
105 30A** Fuel heater (Diesel engine only)
106 30A** Front wiper main
107 40A** Front blower motor
108 40A** Auxiliary blower motor
109 30A** Heated seats
110 50A** Ignition switch
111 30A** 4WD/Shift on the fly
112 30A** Left-hand power seats
113 30A** Starter motor
114 30A** Right-hand power seats
115 20A** Trailer tow battery charge
116 30A** Ignition switch
601 30A CB Window motors, Moonroof
602 60A** 4WABS module
210 — Not used
211 — Backup lamps relay (Diesel engine
only)
212 — Not used
301 — Front blower motor relay
302 — Powertrain Control Module (PCM)
relay
303 — Fuel heater relay (Diesel engine
only)
304 — Heated backlight relay
305 — Trailer tow battery charge relay
306 — Delayed accessory relay
307 — Starter relay
* Mini Fuses ** Maxi Fuses ***Circuit Breaker
2005 U137 Excursion (hdw)
Owners Guide (post-2002-fmt)
USA_English (fus)
