FM5, FM8 & FM10 (All Versions)
Parts List
22
Item Description Item Description
1 Lever Mount Nut 30 Piston Rod
2 Nut Cap M10 31 Lift Handle
3 Lever 32 Screw M6x16
4 Lever Knob 33 Frame Tube
5 Guard Plate 34 Log Guide
6 Nut 35 Spring Washer
7 Copper Gasket 36 Screw M6x10
8 Screw M8 37 Nut
9 O-ring 5.5x2 38 Flat Washer
10 Snap Washer 39 Nut M14
11 Valve Retract Spring 40 Nut Plug
12 O-ring 6x1.5 41 Washer Groupware
13 Valve Core Rod 42 Valve Sleeve
14
Sliding Pressure Sensor Sleeve
43 O-ring 14x1.9
15
Sldng Pressre Sensr Slv Spring
44 Adjusting Screw
16
Aluminium Cover Rear
45 Steel Ball 6
17 O-ring 55x3.1 46 Pressre Limtd Valve Spring
18 Piston 47 Adjusting Screw
19 Piston Ring 48 Moving Carriage
20 O-ring 32x3.5 49 Plastic Insert 1
21 Spring 50 Plastic Insert 2
22 Stud 51 Log Pusher (FM8)
23 Hydraulic Cylinder 52 Nut
24
Aluminium Cover Front
53 Flat Washer
25 Piston Rod Seal 54 Screw
26 O-ring 7x1.9 55 Wheel Cover
27 Wing Bolt M5x12 56 Block Turn
28 Washer Groupware 57 Wheel
29 Dipstick 58 Washer
