Stand/Trolley Assembly
10T Stand
1. Ensure the log splitter is
disconnected from the electricity
supply.
2. Remove the wheels and the
front foot assembly from the log
splitter.
3. Attach the wheels you have
removed, to the stand axles. You
can reuse the circlips or use the
additional split pins supplied.
Note that for all Versions of the
FM5 & FM8, the bar connecting the
front leg to the rear axle, can be
cut in length to shorten it.
4. Attach the rear legs to the log
splitter then mount the splitter on
the stand.
FM5, FM8 & FM10 (All Versions) 27
