320mm
320mm
Position and secure the Braces to the Long Rafters
and Posts, as shown above. Repeat on the other side.
5 6
Position and secure the remaining Notched Rafters to
the Long Rafters.
POST
60MM
SCREWS
TRELLIS
60MM
SCREWS
50MM
SCREWS
LONG RAFTER
Position and secure another Post to the other side of
the Trellis. Ensure the notched ends on the Posts are as
shown above. Repeat the process for the other side.
Position a Post on top of a Trellis, using the
measurements provided. Screw from the outside into
the top and bottom of the Trellis as shown above.
1 2
Position and secure 2 x Notched Rafters to the ends
of the arch as shown above. Secure 1 x Notched Rafter
in the centre of the Long Rafter. Ensure to space the
Notched Rafters evenly.
Position and secure the Long Rafters to the Posts.
Ensure the Long Rafters are ush to the top of the Posts.
Space out the arch to your desired width.
3 4
NOTCHED RAFTER
BRACE
50MM
SCREWS
50MM
SCREWS
