Install fan and radiator
(optional).
H
B
B
C A
A
D
D
A
MB Tray
Fans → 2x 120mm
Radiator up to 240mm
B
TOP
Fans → 3x 120mm
Radiator up to 360mm
C
REAR
Fans → 1x 120mm
D
BOTTOM
Fans → 3x 120mm
Radiator up to 360mm
