8
WARNING: Every time the value “axle to crown” is changed, make sure that
the distance between the crown and the tire is greater than 6 mm.
In addition, make sure that the words “end stroke” on the pipe remains below the
lower plate (3).
Gap / Tire / Crown control
It can also be checked by defeating the
air and checking that 6mm remains.
END STROKE written control
1.1 Triple clamp screws tightening torque
Upper steering triple clamp screws = 6 Nm
Lower steering triple clamp screws = 8 Nm (2 screw per side model).
Corsa + 6mm
