Forney 190 MIG - Tools and Spare Parts List

20
WWW.FORNEYIND.COM
NO. PART NUMBER ITEM DESCRIPTION QTY.
01 21690226K Door latch (1pc pack) 1
02 05000272 Left panel with silk screen and labels 1
03 04600437 Kit spool holder with ring for 5kg spool 1
04
44410068 Wire feeder plast/all d.37 Rul.06-09 1
05 04600145 Motor d.37 + Pinion 1
06 21800051K
4 Lobes d.30 Hand-wheel m8bush 2pcs
pack
2
07 23005501 Mig gun euro connection l=32 1
08 04600114 Kit gas/no gas change board 1
09 04600270 Switch knob d.38 Black 1
10 04600337 Black knob d.38 For potentiom. + Pointer 1
11 04600433 Assembly frame + caps 1
12 21690713 Spacer for plastic frame 1
13 21690805 Torch grommet for euro connection 1
14 22710037 P.C. Board e0795 220/240v + fuse "csa" 1
15 05000279 Dividing panel with labels 1
16 22400038 Rectifier pms 8/4/1 f 1
17 22900014K Solenoid valve 11va 230v 60hz 1 pc pack 1
18 05000276 Rear panel 1
19 22910110 Female gas connector 1/8"gas - 5/8"unf 1
20 21605040K Cable clamp m25x1,5 black 2pcs pack 2
21 20220173
Inp.Power cable3x12awg 4.5M+50a6-
50p plug
1
22 04600286 Fan & fan motor assy. 220V 60hz 1
23 21690261 Cable holder 1
24 22210014K Thermostat 100ø 10a 1 pc pack 1
Tools and Spare Parts List
NO. PART NUMBER ITEM DESCRIPTION QTY.
25 22210016K Thermostat 127ø 16a 1 pc pack 1
26 21690225K Plastic hinge for door 20x30 2pcs pack 2
27 44120178 Transformer mig 180 60hz 220v 40x85 al 1
28 44135018 Choke 40x40 al 1
29
33700414
9005
Bottom panel 1
30 22205159 17A switch "csa" 1
31
05000268 Front panel 190 mig forney w/silk screen 1
32 22610006K Green pilot-lamp 220v l=230 1 pc pack 1
33 21605010K Cable clamp+ring nut,hole d.20,2Pcs pack 2
34 43210120K Earth cable 10gr.Mmq mt. 2 (Pack.1) 1
35 22110033K Earth clamp 300a zinc-coated 1 pc pack 1
36 05000261 Right cover panel with silk screen 1
37
33740579
9005
Torch wrapper 1
38
21600067 Handle for torch wrapper 1
39 21060152K Flat-key 3x3 l=20 1pc pack 1
40 33805071K
Feed roll d.30 0,6-0,9Mm mot2r 1 pc
pack
1
41 33810136 Feed roll secure knob 1
42 23000448
Mig torch 14mm2 3mt tweco 1 euro
connect
1
43 22905101 Gas reducer 2 man. Cga580-5/8" unf-2b 1
44 30900035 Black gas hose 3 meter 1
