less active as the gain control is increased and allows you to select 2 different cap
values with the center position no bright cap. Working both GAIN 1 and GAIN 2 pots
for OD1 in different position with all the combinations of the bright switch positions
gives you a plethora of options to tailor your tone.!
GAIN 2 (inner concentric): Sets your 2nd gain for OD1 with a dedicated 3-way
BRIGHT switch. Settings 12 o’clock and below will can cause high frequency top end
distortion if the BRIGHT switch is engaged. !
GAIN 2 (outer concentric): Sets your 2nd gain for OD2 with a dedicated 3-way
BRIGHT switch. Settings 12 o’clock and below will can cause high frequency top end
distortion if the BRIGHT switch is engaged.!
BRIGHT: 3-way bright switch for GAIN 2 OD2 high frequency boost that becomes
less active as gain control is increased. Working both GAIN 1 and GAIN 2 pots for
OD2 in different position with all the combinations of the bright switch positions gives
you multiple options to tailor your tone.!
CLEAN: Sets your clean channel level. This channel will dirty up a bit after 2 o’clock
and even more with the global SAT switch pulled on the BASS control. This channel !
also loves boost pedals. !
BRIGHT: 3-way bright switch for CLEAN high frequency boost that becomes less
active as gain control is increased. Working the CLEAN pot in different position s
with all the combinations of the bright switch positions gives you tons of options to
tailor your tone.!
TREBLE: Passive interactive high frequency equalization for all channels.!
VIOLENCE OD2: Adds an assignable 4th tube gain stage for OD2 channel.!
MIDDLE: Passive interactive midrange frequency equalization for all channels.!
VIOLENCE OD1: Adds an assignable 4th tube gain stage for OD1channel.!
BASS w/ PULL SAT: Passive interactive low frequency equalization for all channels.
PULL SAT is global saturation for more gain and compression. It is normal for the
sound to drop a bit. In the CLEAN channel, the SAT does not affect the CLEAN channel
until 2 o’clock and beyond on the CLEAN gain control. This way you can set up your
CLEAN channel as clean or crunch with the SAT pulled and higher than 2 o’clock
settings. !
HAIR: 3-way select switch for negative feedback power amp control of high frequency
interaction between amplifier and speakers.!
