FOXCART MARK II
DIMENSIONS
50.5
DIMENSIONS ACROSS HANDLES
31.0
BOX DIMENSION
HANDLE HEIGHT
ABOVE GROUND
BOX HEIGHT
20.0
BOX DIMENSION
GROUND LEVEL
30.0
OUTSIDE WHEELS DIMENSION
21.0
BOX DIMENSION
UNIT WEIGHT − ALL MODELS
1200/1600/2000
APPROX. 600 POUNDS
31.5
25.5
FIGURE 1.
