1. Frontpanel
2. Mounting bracket for fans including
4. Removable upper hdd cage
5. Lower hdd cage
6. hdd mounting bracket
8. ModuVent
9. Noise damping material
11. Fan controller switch
12. Placement for SSD drives **
** SSD drives have to be mounted before motherboard is mounted.
In order to be able to secure screws.
1
2
3
9
11
12
Backside of motherboard tray
