FRAM FFSC-S90MLITGCF-RBK - Page 49

48
Cleaning And Maintenance Of The Oven’s Front Door Glass
Remove the profile by pressing the plastic latches on both left and right sides as shown in figure 21 and
pulling the profile towards yourself as shown in figure 22. Then remove the inner-glass as shown in figure
23. If required, middle glass can be removed in the same way. After cleaning and maintenance are done,
remount the glasses and the profile in reverse order.Make sure the profile is properly seated in its place.
11. INSTALLATION OF THE OVEN DOOR
Completely open the
oven door by pulling
it to yourself.
Afterwards, perform
the unlocking
process by pulling
the hinge lock
upwards with the
help of a screwdriver
as shown in Figure
19.1.
Bring the hinge lock
to the widest angle
as shown in Figure
19.2. Bring both
hinges connecting
the oven door to the
oven to the same
position.
Afterwards, close
the oven door as to
lean on the hinge
lock as shown in
Figure 20.1.
Afterwards, close
the oven door as to
lean on the hinge
lock as shown in
Figure 20.1.
