TORINO INSTALLATION GUIDE
PAGE 4
Remove side cabinet drawer
Install side cabinet
2
7
Install side cabinet top panel
Remove side cabinet drawer
Install side cabinet
6
5
Install top panel4
Consult an expert for the proper
screws/bolts to use when attaching
to various wall constructions.
Screws provided do not attach to all
wall construction types.
IMPORTANT:
3
SILICONE
PAGE 4
SILICONE
