Page 54
"EL" SERIES PARTS LIST
REF. PART NO. DESCRIPTION APPLICATION
E EEE
LLL
223
443
JJJ
333
555
CHASSIS PARTS AA2
31
20 618-233-00 Decorative Panel .......................................................................... 1 1 1
* 618-076-01 Grommet, Suction Line ................................................................. 1 1 1
* 618-148-01 Connector, Fresh Air & Exhaust .................................................... 1 1 1
21 618-066-00 Co ve r, To p ..................................................................................... 1 1 1
22 618-182-01 Insulation, Top Cover .................................................................... 1 1 1
* 618-183-00 Insulation, Left Side Deck ............................................................. 1 1 1
23 618-180-00 Deck ............................................................................................. 1 1 1
* 608-658-10 Filter, Air ....................................................................................... 1 1 1
* 618-230-00 Holder, Filter ................................................................................. 2 2 2
24 618-202-01 Airfoil ............................................................................................ 1 1 1
* 618-206-00 Bracket, Resistor Block ................................................................ 1 1 1
* 915-003-02 Clamp, Supply Cord ...................................................................... 1 1 1
25 605-420-01 Fan Blade ..................................................................................... 1 1 1
26 606-106-02 Blower Wheel ................................................................................ 1 1
26 606-106-09 Blower Wheel ................................................................................ 1
27 618-066-00 Inner Wall ...................................................................................... 1 1 1
28 618-067-00 Mount, Motor ................................................................................ 1 1 1
29 918-077-00 Shroud .......................................................................................... 1 1 1
30 618-100-00 Brace, Shroud............................................................................... 3 3 3
31 618-169-02 Insulation, Inner Wall..................................................................... 1 1 1
32 618-178-00 Blower Front ................................................................................. 1 1 1
33 618-181-00 Scroll ............................................................................................ 1 1 1
34 618-215-00 Door, Slide Assembly ................................................................... 1 1 1
35 618-095-03 Base Pan ...................................................................................... 1
35 618-095-01 Base Pan ...................................................................................... 1 1
* 618-074-00 Drain Pan ...................................................................................... 1 1 1
* 601-799-00 Bellows, Drain Valve ..................................................................... 1 1 1
* 618-188-02 Grille Assembly (Rear) .................................................................. 1 1 1
36 01150934 Grommet, Compressor ................................................................. 3 3 3
37 914-004-00 Bolt, Compressor Mounting .......................................................... 3 3 3
38 618-105-00 Plenum Assembly ........................................................................ 1 1 1
* 618-093-00 Knob, Fresh Air & Exhaust ........................................................... 1 1 1
* 618-096-00 Connector, Louver ......................................................................... 2 2 2
* 618-097-00 Louver .......................................................................................... 20 20 20
* 618-097-01 Louver with Handle ....................................................................... 2 2 2
* 618-092-00 Lever, Fresh Air & Exhaust ........................................................... 1 1 1
39 618-257-02 Outer Shell Assembly (Carton with Sill Plate) ............................... 1 1 1
40 618-084-01 Sill Plate ....................................................................................... 1 1 1
41 618-104-00 Grille, Intake ................................................................................. 1 1 1
* 618-199-00 Latch, Intake Grille ....................................................................... 2 2 2
* WIKL Accessory Package (Optional Window Mount Kit) ......................... 1 1 1
* 608-460-17 Bag Assembly (Hardware) ............................................................ 1 1 1
* Not Shown
To Next Page
