Friedrich Chill CCV18 User Manual

26 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Installation and Operation Manual

THE EXPERTS IN ROOM AIR CONDITIONING

Chill

®

Inverter

115 VOLT CCV15

230 VOLT CCV18, CCV24

Chassis Models

Chill Inverter

®

Series

Room Air Conditioners

93011016_00

Questions and Answers:

M
Melissa SmithAug 15, 2025
Why is my Friedrich Chill CCV18 Air Conditioner not cooling the room sufficiently?
- D
  dbrownAug 16, 2025
  Your Friedrich air conditioner might not be cooling well due to several reasons. Check if the air grille is blocked by obstructions like curtains or furniture. Make sure windows and doors are closed. Adjust the temperature to a cooler setting if needed. Clean or replace a dirty air filter. Also, clean the indoor and outdoor coils if they're obstructed. Reduce excessive heat or moisture in the room. Avoid operating the unit when the outside temperature is below 60 °F (16 °C). If using fan cycling mode, switch to continuous fan for better air circulation. Ensure the unit's cooling capacity matches the room size. Finally, consider that the air conditioner might have insufficient heating capacity.
P
Paul MooreAug 19, 2025
Why Friedrich Chill CCV18 won't start?
- A
  Albert AtkinsAug 19, 2025
  Your Friedrich Air Conditioner might not start due to several reasons: * It might be unplugged, so ensure the plug is completely pushed into the outlet. * A blown fuse or tripped circuit breaker can be the cause; check and replace the fuse or reset the breaker. * A power failure might have occurred; the unit will restart automatically after power is restored, but there's a 3-minute delay to protect the compressor. * The current interrupter device may be tripped; press the RESET button on the power cord plug. If it doesn't stay engaged, stop using the air conditioner and contact a qualified technician.
S
Sarah DixonAug 22, 2025
What to do if my Friedrich Chill CCV18 does not cool as it should?
- S
  Sabrina JohnsonAug 22, 2025
  If your Friedrich Air Conditioner isn't cooling properly, consider these potential causes: * Ensure that curtains, blinds, or furniture aren't blocking the front of the unit. * Lower the thermostat setting. * Clean the air filter, as a dirty filter restricts airflow. * Allow sufficient time for the room to cool down after turning on the air conditioner. * Check for open furnace registers and cold air returns that may be letting cold air escape. * If the cooling coils are frozen, switch to high fan speed and set the thermostat to a higher temperature. * Adjust the temperature sensor so it does not contact the cold coil.
E
Ebony WardAug 25, 2025
Why does my Friedrich Air Conditioner run too much?
- W
  wallacethomasAug 25, 2025
  A Friedrich air conditioner might run excessively due to a high heat load in the room from appliances or many occupants; the unit needs to work harder to remove the extra heat. Also, the unit might be improperly sized for the room. Higher efficiency models may also run longer, which is normal. The actual energy usage will be significantly less when compared to older models.
B
Brandi GoodmanAug 28, 2025
How to fix a Friedrich Air Conditioner remote control that is not working?
- C
  Chelsey SmithAug 28, 2025
  If your Friedrich Air Conditioner remote control isn't working, check the following: * Ensure the batteries are inserted correctly. * Replace the batteries if they are dead.
J
Jacqueline ClarkAug 30, 2025
What to do if my Friedrich Chill CCV18 unit does not operate?
- J
  janiceburnsAug 30, 2025
  If your Friedrich air conditioner isn't working, first ensure it's turned on and the thermostat is properly set. Check if the LCDI power cord is plugged into a grounded outlet. If the reset button on the LCDI power cord has popped out, press it to resume operation. Also, verify that the circuit breaker hasn't tripped or the fuse blown, resetting or replacing them if necessary. Lastly, if there was a power failure, the unit should resume operation after power is restored, but there may be a 3-minute delay.
C
Courtney LongSep 2, 2025
Why does my Friedrich Air Conditioner trip the circuit breaker?
- A
  Ashley NicholsSep 2, 2025
  Your Friedrich air conditioner might be tripping the circuit breaker or blowing fuses because it's sharing a circuit with other appliances; it needs a dedicated circuit. Avoid using extension cords with the unit. Also, the circuit breaker or fuse might not be rated correctly; replace it with the proper rating. If problems persist, consult a licensed electrician.
D
Dana ShannonSep 6, 2025
What to do if the LCDI power cord trips on my Friedrich Air Conditioner?
- E
  Eric GreeneSep 6, 2025
  The LCDI power cord on your Friedrich air conditioner may trip due to power supply disturbances, electrical overload, overheating, or a pinched cord. To resume operation, press and release the RESET button. Ensure any underlying issues like overloading or cord damage are resolved first.
G
George FosterSep 8, 2025
Why is my Friedrich Chill CCV18 Air Conditioner making noise when it starts?
- R
  Ryan DeleonSep 9, 2025
  The “da-da” sound you hear for about 30 seconds when your Friedrich air conditioner starts is normal. It's just the compressor starting up.
D
David GarciaSep 12, 2025
Why is water dripping inside my Friedrich Air Conditioner when cooling?
- H
  hillandreaSep 12, 2025
  If you notice water dripping inside your Friedrich Air Conditioner while it's cooling, it could be due to these reasons: * The unit might not be correctly tilted to the outside. Ensure it's slightly tilted to allow for proper water drainage. * Moisture removed from the air is draining into the base pan. This is normal for a short period in areas with low humidity and for a longer period in areas with high humidity.

Friedrich Chill CCV18 Specifications

General

Type	Window Air Conditioner
Cooling Capacity	18, 000 BTU
Fan Speeds	3
Voltage	115V
Refrigerant	R-32
Power Supply	115V/60Hz
Cooling Area	Up to 1, 000 sq. ft.
Smart Features	Wi-Fi Enabled
Window Size	41 inches (width)
Noise Level	54 dB

Summary

A. IMPORTANT SAFETY AND GENERAL INFORMATION

A.1 Introduction

Provides an overview of the manual's content and purpose.

A.2 Safety Warnings

Details critical safety alerts, symbols, and precautions for safe operation.

A.3 Importance of a Quality Installation

Explains how proper installation ensures optimal performance and longevity.

A.4 Product Inspection / Packing List

Guides users on inspecting the unit for damage and verifying contents.

B. SPECIFICATIONS

B.1 Dimensions

Details the physical measurements of the air conditioner unit.

C. INSTALLATION OF THE UNIT

C.1 Pre-Installation Checkpoints

Lists essential checks and considerations before beginning the installation process.

C.2 Tools Required

Lists the tools necessary for the installation process.

C.3 Choosing a Location

Guidance on selecting the optimal placement for the air conditioner.

C.4 Window Installation

Details requirements and steps for installing the unit in a window.

C.5 Thru-the-Wall Installation

Details requirements and steps for installing the unit through a wall.

E. ELECTRICAL

E.1 Electrical Safety Information

Details essential electrical safety precautions, including warnings about shock hazards.

E.2 Testing the Power Cord

Explains how to test the unit's Leakage Current Detection Interrupter (LCDI) power cord.

J. STARTUP AND OPERATION

J.1 Control Panel Operation

Explains the functions of buttons and indicators on the unit's control panel.

J.2 Remote Control Operation

Describes how to use the remote control and its various functions.

J.5 Start-up

Discusses normal operating conditions, condensation, frosting, and noises.

M. TROUBLESHOOTING

M.1. Troubleshooting Tips

A table listing complaints, their causes, and recommended solutions.

R. INFORMATION FOR THE OWNER

R.1 Maintenance

Details how to clean the air filter, cabinet, and prepare for winter storage.
