Friedrich MWM12Y1J Service & Parts Manual

65 PB
Removal
Indoor Unit
a
b
Pay attention to the direction
of the retainer of the
thermistor so that the
retainer will not touch the
harness (same as the
existing models.)
Take care not to losw the clip
of thermistor
board
Terminal
Connecting
wires
Heat exchanger thermistor
Heat exchanger
thermistor
c
Clip
Disconnect the Cable
clamp
Remove Temperature
Sensor; Disconnect the
connection wires.
Twist off the earthing screw
fixing the evaporator;
Pull out the all the wiring
terminals
Remove a screw on the
electrical box.
