PARTS CATALOG
PZE07K3SB, PZE09K3SB, PZE09R3SB, PZE12K3SB, PZE12R3SB, PZE15K3SB
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
21 67808071 OUTDOOR MOTOR PZE07K3SB, PZE09K3SB, PZE12K3SB 1
21 67808082 OUTDOOR MOTOR PZE09R3SB 1
21 67808092 OUTDOOR MOTOR PZE12R3SB 1
21 67808022 OUTDOOR MOTOR PZE15K3SB 1
22 67808023 OUTDOOR FAN BLADE ALL 1
23 67808024 OUTDOOR LOUVER ALL 1
24 67808025 TOP AIR GUIDE ALL 1
25 67808026 INDOOR FAN GUARD ALL 1
26 67808027 EVAPORATOR COIL ALL 1
27 67808028 INDOOR BLOWER HOUSING ALL 1
28 67808029 BASE PAN ALL 1
29 67808030 TOP SUPPORT BRACKET ALL 1
30 67812168 CLAPBOARD ALL 1
31 67808032 FAN SHROUD ALL 1
32 67808066 CONDENSER COIL PZE07K3SB 1
32 67808033 CONDENSER COIL PZE09K3SB, PZE12K3SB, PZE09R3SB, PZE12R3SB, PZE-
15K3SB
1
33 67808034 BLOWER END PLATE ALL 1
34 67808035 BLOWER BEARING ALL 1
35 67808036 FAN WHEEL RIGHT CLIP ALL 1
36 67808037 FAN WHEEL LEFT CLIP ALL 1
37 67808038 BLOWER WHEEL BEARING ALL 1
38 67808039 BLOWER END PLATE ALL 1
39 67808040 SENSOR HOLDER ALL 1
40 67808070 INDOOR MOTOR PZE07K3SB , PZE09K3SB 1
40 67808083 INDOOR MOTOR PZE09R3SB 1
40 67812105 INDOOR MOTOR PZE12K3SB 1
40 67808093 INDOOR MOTOR PZE12R3SB 1
40 67808041 INDOOR MOTOR PZE15K3SB 1
41 67808042 BLOWER WHEEL ALL 1
42 67808043 DISCHARGE LOUVER ALL 1
43 67808044 AIR FILTER ALL 1
44 67808045 FRESH AIR FILTER ALL 1
45 67808067 CONDENSER HEADER ASSY PZE07K3SB 1
45 67808076 CONDENSER HEADER ASSY PZE09K3SB 1
45 67808094 CONDENSER HEADER ASSY PZE09R3SB, PZE12R3SB 1
45 67812106 CONDENSER HEADER ASSY PZE12K3SB 1
45 67812111 CONDENSER HEADER ASSY PZE15K3SB 1
46 67808069 EVAPORATOR DISTRIBUTOR
ASSY
PZE07K3SB 1
Figure 901
