# = Fast Moving Part 11 06/03
* = Non-Illustrated Part
FDB2310LC Publication No.
5995392171
FRAME
A = FDB2310LC (FDB2310LCS0)
B = FDB2310LC (FDB2310LCQ0)
C = FDB2310LC (FDB2310LCB0)
D = FDB2310LC (FDB2310LCC0)
POS. NO PART NO DESCRIPTION
3 # 154445901 A B C D Valve,water
4 154208701 A B C D Brace,front frame
8 154322901 A - - - Toeplate,adjustable ,white
8 154322905 - B - - Toeplate,adjustable ,bisque
8 154322903 - - C D Toeplate,adjustable ,black
9 154397201 A - - - Kickplate Assy,white ,w/foam
9 154397204 - B - - Kickplate Assy,bisque ,w/foam
9 154397203 - - C D Kickplate Assy,black ,w/foam
10 154371301 A - - - Screw,phillips head ,white
10 154371303 - B - - Screw,phillips head ,bisque
10 5300808658 - - C D Screw,#8A x .375" ,black
11 154409401 A B C D Screw,#8-18 x .375
11A 154200601 A B C D Screw,#10-16 x 3/8
15 154419301 A B C D Screw,leveling
20 154209601 A B C D Cover,junction box
* 154041001 A B C D Screw,plask #1 ,10-10 x 9/16
* 154200602 A B C D Screw,10-16 x 3/8 ,hex
