Frigidaire FDB2310LC - Page 13

# = Fast Moving Part 13 06/03
* = Non-Illustrated Part
FDB2310LC Publication No.
5995392171
RACKS
A = FDB2310LC (FDB2310LCS0)
B = FDB2310LC (FDB2310LCQ0)
C = FDB2310LC (FDB2310LCB0)
D = FDB2310LC (FDB2310LCC0)
POS. NO PART NO DESCRIPTION
1 154432603 A B C D Rack assy,lower
2 154424001 A B C D Basket,silverware ,main
2A 154424101 A B C D Basket,silverware ,(2) ,side
3 154319524 A B C D Rack assy,upper
4 5304407064 A B C D Wheel & bushing assy,upper rack
5 5300809927 A B C D Cap,slide ,(4)
6 154232701 A B C D Slide,rack ,(2)
7 154174501 A B C D Wheel & bracket assy,lower rack
8 154304001 A B C D Base,funnel
9 154251801 A B C D Funnel
10 154466901 A B C D Basket,utility ,white
11 154436101 A B C D Shelf,cup ,half width ,white
13 154425502 A B C D Fence,fold down ,lower rack ,(2) ,full length
14 154428401 A B C D Bracket,fold down fence ,lower rack ,(6)
16A 154424301 A B C D Cover,side basket ,(2) ,silverware
