# = Fast Moving Part 5 06/03
* = Non-Illustrated Part
FDB2310LC Publication No.
5995392171
A = FDB2310LC (FDB2310LCS0)
B = FDB2310LC (FDB2310LCQ0)
C = FDB2310LC (FDB2310LCB0)
D = FDB2310LC (FDB2310LCC0)
POS. NO PART NO DESCRIPTION
1 154430601 A B C D Spring,door ,(2)
1A 154325201 A B C D Linkage,door spring ,(2)
2 154093301 A B C D Screw,arm assy ,(4)
3 154325304 A B C D Arm Assy,LH
3A 154325303 A B C D Arm Assy,RH
* 154400601 A B C D Pin,arm assy
5 154079601 A B C D Nut,arm assy ,and handle mtg.
7 154299004 A B C D Door,inner assy
9 154230103 A B C D Dispenser,det/rinse aid ,includes #22
9* 154294701 A B C D Screw,#7 plas .375 ,(6) ,disp. assy.
10 154103702 A B C D Screw,latch mtg ,(2)
12 # 154475101 A - - - Latch assy,white
12 # 154475104 - B - - Latch assy,bisque
12 # 154475103 - - C D Latch assy,black
20 154359006 A - - - Door,white
20 154359008 - B - - Door,bisque
20 154359007 - - C - Door,black
20 154359012 ---D Door,stainless
20* 5304428306 A B C D Screw,door mtg. ,(2)
22 154388801 A B C D Cap,Rinse aid
49 154297603 A B C D Gasket,door ,bottom
50 154211401 A B C D Support,door hinge
51 154320301 A B C D Clamp,drip loop ,wire
* 154200601 A B C D Screw,#10-16 x 3/8
DOOR
