# = Fast Moving Part 7 06/03
* = Non-Illustrated Part
FDB2310LC Publication No.
5995392171
A = FDB2310LC (FDB2310LCS0)
B = FDB2310LC (FDB2310LCQ0)
C = FDB2310LC (FDB2310LCB0)
D = FDB2310LC (FDB2310LCC0)
POS. NO PART NO DESCRIPTION
1 # 154209301 A B C D Tub assy,w/frame parts
2 154429101 A B C D Strike,door
3 # 154211801 A B C D Gasket,tub
4 154200602 A B C D Screw,10-16 x 3/8 ,hex
5 154333902 A B C D Roller,tub
6 5303943103 A B C D Screw,w/washer ,(8)
22 154239801 A B C D Tubing,water inlet
23 5303318539 A B C D Clamp,tubing ,(2)
24 # 154411003 A B C D Hose,drain
25 # 154209701 A B C D Float
28 154408701 A B C D Switch assy,float
29 # 154290204 A B C D Thermostat,re-settable
30 154241101 A B C D Retainer,thermostat
30* 154297701 A B C D Screw,retainer-thermo
* 154447102 A B C D Insulation,blanket
* 154447301 A B C D Insulation,tub back
* 154041001 A B C D Screw,plask #1 ,10-10 x 9/16
* 5300807270 A B C D Screw,(2) ,countertop mtg.
TUB
