# = Fast Moving Part 3 10/00
* = Non-Illustrated Part
FDB345LF Publication No.
5995344438
CONTROL PANEL
A = FDB345LF (FDB345LFS1)
B = FDB345LF (FDB345LFR1)
POS. NO PART NO DESCRIPTION
1 154368301 A - Panel-control,white
1 154368303 - B Panel-control,black
2 154333801 A - Insert-control pnl,white
2 154333803 - B Insert-control pnl,black
3 # 154295701 A B Timer
3* 154095701 A B Screw-timer,thread rolling ,(2)
3* 154131203 A B Shield-timer
8 154334101 A B Switch
8* 154242201 A B Shield-switch
8* 5303318719 A B Screw,mtg.
12 154236502 A - Pushbutton,white ,(2)
12 154236501 - B Pushbutton,black ,(4)
13 154239501 A - Knob-timer,white
13 154239503 - B Knob-timer
20 154283701 A B Vapor Weldment Assy
25 154229201 A B Seal-chamber
26 154303901 A B Gasket-vent
27 154226701 A B Actuator-wax
28 154226901 A B Valve-vent
29 154226403 A B Gasket-valve
* 154283901 A B Screw,#8-10 ,3/8 phillips
* # 154385101 A B Harness-wiring
To Next Page
