# = Fast Moving Part 9 10/00
* = Non-Illustrated Part
FDB345LF Publication No.
5995344438
A = FDB345LF (FDB345LFS1)
B = FDB345LF (FDB345LFR1)
POS. NO PART NO DESCRIPTION
1 # 154247601 A B Heater
1* 154106201 A B Nut-heater,(2)
1* 154289801 A B Shield-heater terminal
2 154359701 A B Bracket-heater,(2)
10 154245501 A B Cover-volute
13 154246801 A B Gasket-sump
14 154365902 A B Housing-sump
16 154246502 A B Retainer,sump
16* 5304404947 A B Screw,retainer
24 154250801 A B Spray arm-lower
24A 154313601 A B Spray arm-center
24A* 154252001 A B Nut-spray arm
32 154251701 A B Tube-delivery
32A 154358901 A B Gasket-delivery tube
34 154064901 A B Washer-insulating
40 154348401 A B Clamp,red ,pump
40 154348501 A B Clamp,silver ,pump
40* 154106801 A B Clamp-hose,(2)
54 154234401 A B Hose-connector
55 154362301 A B Bracket-motor
55* 5303316032 A B Screw,truss ss ,8 .625
58 154246402 A B Check ball
59 154246901 A B O-ring,rear
59A 154247001 A B O-ring,front
60 154247502 A B Drain Pump Assy
60* 154234501 A B Bracket-motor,drain
61 154359601 A B Nozzle,3rd level ,spray arm
62 154294101 A B Support-spray arm
63 154252201 A B Base-soil director
64 154252301 A B Filter-soil director
65 154252401 A B Filter-polypro
66 154252701 A B Trap-glass
70 # 154369501 A B Motor assembly,circulation ,w/o o’rings
* 154338601 A B Clamp-P,nylon
MOTOR & PUMP
