# = Fast Moving Part 5 04/03
* = Non-Illustrated Part
FDB510LC Publication No.
5995389672
A = FDB510LC (FDB510LCS0)
B = FDB510LC (FDB510LCB0)
POS. NO PART NO DESCRIPTION
1 154413301 A B Spring,door ,(2)
1A 154325201 A B Linkage,door spring ,(2)
2 154093301 A B Screw,arm assy ,(4)
3 154325304 A B Arm Assy,LH
3A 154325303 A B Arm Assy,RH
* 154400601 A B Pin,arm assy
5 154079601 A B Nut,arm assy ,and handle mtg.
7 154299004 A B Door,inner assy
9 154230103 A B Dispenser,det/rinse aid ,includes #22
9* 154294701 A B Screw,#7 plas .375 ,(6) ,disp. assy.
10 154103702 A B Screw,latch mtg ,(2)
12 154434101 A - Latch assy,white
12 154434103 - B Latch assy,black
20 154359105 A - Door,white
20 154359107 - B Door,black
20* 5304428306 A B Screw,door mtg. ,(2)
22 154388801 A B Cap,Rinse aid
49 154297603 A B Gasket,door ,bottom
50 154211401 A B Support,door hinge
51 154320301 A B Clamp,drip loop ,wire
* # 154227806 A B Thermostat,temp boost ,hi temp rinse
DOOR
