# = Fast Moving Part 7 04/03
* = Non-Illustrated Part
FDB510LC Publication No.
5995389672
A = FDB510LC (FDB510LCS0)
B = FDB510LC (FDB510LCB0)
POS. NO PART NO DESCRIPTION
1 # 154209301 A B Tub assy,w/frame parts
2 154429101 A B Strike,door
3 # 154211801 A B Gasket,tub
4 154200602 A B Screw,10-16 x 3/8 ,hex
5 154333902 A B Roller,tub
6 5303943103 A B Screw,w/washer ,(8)
22 154239801 A B Tubing,water inlet
23 5303318539 A B Clamp,tubing ,(2)
24 # 154411003 A B Hose,drain
25 # 154209701 A B Float
28 154408701 A B Switch assy,float
29 # 154290204 A B Thermostat,re-settable
30 154241101 A B Retainer,thermostat
30* 154297701 A B Screw,retainer-thermo
* 154456901 A B Insulation,blanket
* 154041001 A B Screw,plask #1 ,10-10 x 9/16
* 154200601 A B Screw,#10-16 x 3/8
* 5300807270 A B Screw,(2) ,countertop mtg.
TUB
