# = Fast Moving Part 5 04/01
* = Non-Illustrated Part
FDB635RF Publication No.
5995352712
A = FDB635RF (FDB635RFS5)
B = FDB635RF (FDB635RFR5)
POS. NO PART NO DESCRIPTION
1 154365701 A B Spring-door,(2)
1A 154325201 A B Spring linkage,(2)
2 154093301 A B Screw-arm assy,(4)
3 154325304 A B Arm Assy,LH
3A 154325303 A B Arm Assy,RH
* 154211501 A B Pin-arm
5 154079601 A B Nut-arm assy,(4)
7 154299002 A B Door-inner assy
7A 154226601 A B Liner grate
9 154230101 A B Dispenser-det/rinse aid,includes #22
9* 154294701 A B Screw,#7 plas .375 ,(6) ,disp. assy.
10 154103702 A B Screw-latch mtg,(2)
12 # 154361201 A - Latch assy,white
12 # 154361203 - B Latch assy,black
20 154327701 A B Mid Door Assy
22 154388801 A B Cap-rinse aid
27 154257601 A - Trim-door,white ,bottom
27 154257603 - B Trim-door,black ,bottom
32 5303943148 A B Insert-door kit,wht/alm&blk/wht
32A 154229001 A B Spacer-insert,door
36 154254201 A - Trim-door,white ,side
36 154254203 - B Trim-door,side
49 154297602 A B Gasket-door,bottom
50 154211401 A B Support-door hinge
51 154320301 A B Clamp-wire,drip loop
* # 154227805 A B Thermostat-temp assure
* # 154227808 A B Thermostat-temp boost
* 5300808749 A B Screw,C.R. truss ,#8 .625
DOOR
