# = Fast Moving Part 7 04/01
* = Non-Illustrated Part
FDB635RF Publication No.
5995352712
A = FDB635RF (FDB635RFS5)
B = FDB635RF (FDB635RFR5)
POS. NO PART NO DESCRIPTION
1 # 154209301 A B Tub assy,w/frame parts
2 154211601 A B Strike-door
3 # 154211801 A B Gasket-tub
4 154200602 A B Screw,10-16 x 3/8 ,hex
5 154333901 A B Roller-tub
6 5303943103 A B Screw w/washer,(8)
22 154239801 A B Tubing-water inlet
23 5303318539 A B Clamp-tubing,(2)
24 # 154225602 A B Hose-drain
25 # 154209701 A B Float
28 # 154225501 A B Switch-float
28A 154386601 A B Bracket-float switch
28A* 154333301 A B Screw,bracket mtg ,ph truss head
29 # 154290204 A B Thermostat,re-settable
30 154241101 A B Retainer-thermostat
30* 154297701 A B Screw,retainer-thermo
* 154200601 A B Screw-#10-16 x 3/8
* 154238304 A B Insulation,tub
* 154360201 A B Insulation,blanket ,back
* 5300807270 A B Screw,(2) ,countertop mtg.
TUB
