# = Fast Moving Part 5 09/01
* = Non-Illustrated Part
FDB641RA Publication No.
5995358925
A = FDB641RA (FDB641RAS0)
B = FDB641RA (FDB641RAB0)
POS. NO PART NO DESCRIPTION
1 154345902 A B Spring,door ,(2)
1A 154325201 A B Linkage,door spring ,(2)
2 154093301 A B Screw,arm assy ,(4)
3 154325304 A B Arm Assy,LH
3A 154325303 A B Arm Assy,RH
* 154211501 A B Pin,arm
5 154079601 A B Nut,arm assy ,(4)
7 154299002 A B Door,inner assy
7A 154332701 A B Grate,liner
9 154230101 A B Dispenser,det/rinse aid ,includes #22
9* 154294701 A B Screw,#7 plas .375 ,(6) ,disp. assy.
10 154103702 A B Screw,latch mtg ,(2)
12 # 154361201 A - Latch assy,white
12 # 154361203 - B Latch assy,black
20 154359105 A - Door,white
20 154359107 - B Door,black
22 154388801 A B Cap,Rinse aid
49 154297602 A B Gasket,door ,bottom
50 154211401 A B Support,door hinge
51 154320301 A B Clamp,drip loop ,wire
* # 154227808 A B Thermostat,temp boost
* 154200601 A B Screw,#10-16 x 3/8
DOOR
