# = Fast Moving Part 11 02/03
* = Non-Illustrated Part
FDBB944C Publication No.
5995386322
FRAME
A = FDBB944C (FDBB944CS0)
B = FDBB944C (FDBB944CB0)
C = FDBB944C (FDBB944CC0)
D = FDBB944C (FDBB944CQ0)
POS. NO PART NO DESCRIPTION
3 # 154373303 A B C D Valve,water
4 154208701 A B C D Brace,front frame
8 154322901 A - - - Toeplate,adjustable ,white
8 154322903 - B C - Toeplate,adjustable ,black
8 154322905 ---D Toeplate,adjustable ,bisque
9 154397201 A - - - Kickplate Assy,white ,w/foam
9 154397203 - B C - Kickplate Assy,black ,w/foam
9 154397204 ---D Kickplate Assy,bisque ,w/foam
10 154371301 A - - - Screw,phillips head ,white
10 5300808658 - B C - Screw,#8A x .375" ,black
10 154371303 ---D Screw,phillips head ,bisque
11 154409401 A B C D Screw,#8-18 x .375
11A 154200601 A B C D Screw,#10-16 x 3/8
15 154419301 A B C D Screw,leveling
20 154209601 A B C D Cover,junction box
* 154041001 A B C D Screw,plask #1 ,10-10 x 9/16
* 154200602 A B C D Screw,10-16 x 3/8 ,hex
