# = Fast Moving Part 5 10/02
* = Non-Illustrated Part
FDBL960B Publication No.
5995379459
A = FDBL960B (FDBL960BS0)
B = FDBL960B (FDBL960BB0)
C = FDBL960B (FDBL960BQ0)
POS. NO PART NO DESCRIPTION
1 154414001 A B C Spring,door ,(2)
1A 154325201 A B C Linkage,door spring ,(2)
2 154093301 A B C Screw,arm assy ,(4)
3 154325304 A B C Arm Assy,LH
3A 154325303 A B C Arm Assy,RH
* 154400601 A B C Pin,arm assy
5 154079601 A B C Nut,arm assy ,and handle mtg.
7 154299004 A B C Door,inner assy
9 154230103 A B C Dispenser,det/rinse aid ,includes #22
9* 154294701 A B C Screw,#7 plas .375 ,(6) ,disp. assy.
10 154103702 A B C Screw,latch mtg ,(2)
12 # 154361201 A - - Latch assy,white
12 # 154361203 - B - Latch assy,black
12 # 154361204 - - C Latch assy,bisque
20 154436809 A - - Door assy,white ,outer
20 154436808 - B - Door assy,black ,outer
20 154436810 - - C Door assy,bisque ,outer
20* 154253201 A B C Insulation,door
20* 5304428306 A B C Screw,door mtg. ,(2)
22 154388801 A B C Cap,Rinse aid
41 154448901 A - - Handle,towel bar ,white ,w/thrdd stud
41 154448903 - B - Handle,towel bar ,black ,w/thrdd stud
41 154448904 - - C Handle,towel bar ,bisque ,w/thrdd stud
49 154297603 A B C Gasket,door ,bottom
50 154211401 A B C Support,door hinge
51 154320301 A B C Clamp,drip loop ,wire
53 154425001 A B C Nut,Keps ,(2) ,handle mtg.
* 154200601 A B C Screw,#10-16 x 3/8
DOOR
