Frigidaire FDBL960B - Tub and Frame Parts; Door Strike and Gasket; Water Inlet and Drain; Float Switch and Thermostat

# = Fast Moving Part 7 10/02
* = Non-Illustrated Part
FDBL960B Publication No.
5995379459
A = FDBL960B (FDBL960BS0)
B = FDBL960B (FDBL960BB0)
C = FDBL960B (FDBL960BQ0)
POS. NO PART NO DESCRIPTION
1 # 154209301 A B C Tub assy,w/frame parts
2 154429101 A B C Strike,door
3 # 154211801 A B C Gasket,tub
4 154200602 A B C Screw,10-16 x 3/8 ,hex
5 154333902 A B C Roller,tub
6 5303943103 A B C Screw,w/washer ,(8)
22 154239801 A B C Tubing,water inlet
23 5303318539 A B C Clamp,tubing ,(2)
24 # 154411003 A B C Hose,drain
25 # 154209701 A B C Float
28 154408701 A B C Switch assy,float
29 # 154290204 A B C Thermostat,re-settable
30 154241101 A B C Retainer,thermostat
30* 154297701 A B C Screw,retainer-thermo
* 154238304 A B C Insulation,tub
* 154360201 A B C Insulation,blanket ,back
* 154041001 A B C Screw,plask #1 ,10-10 x 9/16
* 5300807270 A B C Screw,(2) ,countertop mtg.
TUB
