Frigidaire FDBL960B User Manual

# = Fast Moving Part 9 10/02
* = Non-Illustrated Part
FDBL960B Publication No.
5995379459
A = FDBL960B (FDBL960BS0)
B = FDBL960B (FDBL960BB0)
C = FDBL960B (FDBL960BQ0)
POS. NO PART NO DESCRIPTION
1 # 154247601 A B C Heater
1* 154106201 A B C Nut,heater ,(2)
1* 154289801 A B C Shield,heater terminal
2 154359701 A B C Bracket,heater ,(2)
10 154245501 A B C Cover,volute
13 154246801 A B C Gasket,sump
14 154365901 A B C Housing,sump
16 154246502 A B C Retainer,sump
24 154414101 A B C Spray arm,lower ,w/heat shield
24A 154313601 A B C Spray arm,center
24A* 154252001 A B C Nut,spray arm ,center
32 154406601 A B C Tube,delivery
32A 154406401 A B C Gasket,delivery tube
40 154348401 A B C Clamp,red ,pump
40 154348501 A B C Clamp,silver ,pump
40* 154106801 A B C Clamp,hose ,(2)
40* 154380601 A B C Clamp,hose ,(1)
54 154234401 A B C Hose,connector
55 154362301 A B C Bracket,motor ,askoll
55* 5303316032 A B C Screw,truss ss ,8 .625
58 154246402 A B C Check ball
59 154246901 A B C O-ring,rear
59A 154247001 A B C O-ring,front
60 154407401 A B C Drain Pump Assy
60* 154426201 A B C Bracket,motor ,drain
61 154406501 A B C Nozzle,3rd level ,spray arm
62 154294101 A B C Support,spray arm ,lower
63 154252201 A B C Base,soil director
64 154252301 A B C Filter,soil director
65 154252401 A B C Filter,polypro
66 154252701 A B C Trap,glass
70 # 154418301 A B C Motor assembly,circulation ,w/o o’rings
71 154366101 A B C Sensor,turbidity
71* 154376001 A B C O-ring,turbidity
* 154200601 A B C Screw,#10-16 x 3/8
MOTOR & PUMP
