# = Fast Moving Part 5 10/00
* = Non-Illustrated Part
FDR251RJ Publication No.
5995344487
A = FDR251RJ (FDR251RJS0)
B = FDR251RJ (FDR251RJR0)
POS. NO PART NO DESCRIPTION
1 154237401 A B Spring-door,(2)
2 154093301 A B Screw-arm assy,(4)
3 5303270031 A B Arm Assy,RH & LH
3* 154221401 A B Cover-arm
3* 5303298513 A B Pin-arm
4 5300805884 A B Pad-spring
5 154079601 A B Nut-arm assy,(4)
7 154352201 A B Door-inner assy
9 154230101 A B Dispenser-det/rinse aid
9* 154294701 A B Screw,#7 plas .375 ,(6) ,disp. assy.
10 154026601 A B Speednut-baffle
11 # 154221101 A B Baffle seal
12 # 154361201 A - Latch assy,white
12 # 154361203 - B Latch assy,black
15 154103702 A B Screw-latch mtg,(2)
20 5303308615 A B Panel-door,galv
21 5303318023 A B Panel-access,galv
25 5300809055 A B Screw,cr truss s.s. ,8 .438
27 5303303652 A B Trim-door,chrome ,bottom
28 5300808471 A B Trim-access top,chrome
32 5300808756 A B Insert-door/access,alm/blk
32 5303318022 A B Insert-door,wht/clr
32 5303318024 A B Insert-access,wht/clr
33 5303318540 A B Screw-door trim,phillips ,8-18
36 5303943080 A B Trim-door,chrome ,RH & LH
38 5303272124 A B Trim-access panel,chrome ,RH
39 5303272125 A B Trim-access panel,chrome ,LH
40 154043802 A B Trim-access,chrome ,bottom
43 154229301 A B Cover-vent
43* 154229401 A B Screw-vent cover,(2)
44 154221001 A B Gasket,vent cover
51 154320301 A B Clamp-wire,drip loop
* 154227808 A B Thermostat-temp boost
DOOR
