# = Fast Moving Part 9 10/00
* = Non-Illustrated Part
FDR251RJ Publication No.
5995344487
A = FDR251RJ (FDR251RJS0)
B = FDR251RJ (FDR251RJR0)
POS. NO PART NO DESCRIPTION
1 # 154220901 A B Heater
1* 154289801 A B Shield-heater terminal
2 154359701 A B Bracket-heater,(2)
3 154106201 A B Nut-heater,(2)
7 154365101 A B Macerator
10 154365301 A B Cover-volute
12 154365401 A B Impeller-lower
12A 154365501 A B Slinger-pump
14 154364801 A B Housing-pump
15 # 154367701 A B Check valve
16 154246502 A B Retainer,sump
18 # 154384301 A B Motor
22 154200201 A B Screw-pump housing
23 154234301 A B Nut-spray arm
24 154219201 A B Spray arm-lower
27 154377501 A B Screw-upper impeller
28 154370601 A B Impeller-upper
34 154064901 A B Washer-insulating
35 154200901 A B Screw-motor mtg
36 154381001 A B Sleeve & seal assy.
38 154367402 A B Diffuser
42 154365601 A B Gasket-pump
44 154122502 A B Base-tower
45 154122601 A B Middle-tower
46 154122701 A B Tip-tower
52 154365201 A B Cover,pump housing
* 154200601 A B Screw-#10-16 x 3/8
* 154380601 A B Clamp-hose
MOTOR & PUMP
