- 2 -
24” AND 27” SINGLE OVENS
FIGURE 1
Allow at least 19-3/8” clearance for complete oven door
opening as show in FIGURE 8.
DO NOT INSTALL THIS OVEN IN A BASE CABINET
WITH A COUNTERTOP ABOVE IT.
PRODUCT DIMENSIONS AND CABINET WIDTH
MODEL
24” SINGLE OVEN 23-7/8” 21-11/16” 24” MIN.
27” SINGLE OVEN
3”
MAX.
1-7/8”
MIN.
HOLE
FOR
CABLE
F
E
C
1-1/2”
MIN.
31”
*
*
18” MINIMUM
6’ CABLE
28-1/32”
D
B
30-3/4”
A
25-3/8”
ELECTRICAL
JUNCTION
BOX
Min.
26-7/8” 24-11/16” 27” MIN.
24”
SINGLE
OVEN
27”
SINGLE
OVEN
28-1/8” 22” 23-1/2”
Max. 30-1/8” 22-1/4” –
Min. 28-1/8” 24-7/8” 23-1/2”
Max. 30-1/8” 25-1/4” –
ABC
MODEL D E F
CUTOUT DIMENSIONS
24” AND 27” DOUBLE OVENS
FIGURE 2
Allow at least 19-3/8” clearance for complete oven door
opening as show in FIGURE 8.
PRODUCT DIMENSIONS AND CABINET WIDTH
MODEL
24” DOUBLE OVEN 23-7/8” 21-11/16” 24” MIN.
27” DOUBLE OVEN
Min.
26-7/8”
27-1/8” **
24-11/16” 27” MIN.
24”
DOUBLE
OVEN
27”
DOUBLE
OVEN
48” 22” 23-1/2”
Max. 50” 22-1/4” –
Min. 48” 24-7/8” 23-1/2”
Max. 49-7/8” 25-1/4” –
ABC
MODEL D E F
CUTOUT DIMENSIONS
3”
MAX.
1-7/8”
MIN.
HOLE
FOR
CABLE
F
E
C 1-1/2”
MIN.
11-1/2”
6’ CABLE
47-3/4”
D
B
49-1/4”
A
25-3/8”
ELECTRICAL
JUNCTION
BOX
** 27-1/8” on stainless steel models.
