# = Fast-moving Parts 7 12/01
* = Non-Illustrated Parts
FFC07C4AW1/2 Publication No.
5995363685
SYSTEM
A = FFC07C4A (FFC07C4AW1)
B = FFC07C4A (FFC07C4AW2)
POS. NO PART NO DESCRIPTION
1 # 5300120780 A B Condenser
4 216634500 A B Drier-filter
5 216807100 A - Harness-main
5 216830600 - B Harness-main
22 216056400 A B Clip-spring mtg
27 5308002681 A - Grommet,compressor
27 216337700 - B Screw,hex washer head ,10-24 x 0.500
29 # 216820500 A - Compressor,w/o electricals
29 # 216784200 - B Compressor,w/o electricals
30 216649305 A - Controller
30 216649314 - B Controller
32 216694500 A - Clip,controller
32 216649200 - B Clip,controller
55 216696700 A - Capacitor-run,180 VAC ,15 microfarad
55 # 216787800 - B Capacitor-run
86 216707700 A B Screw,8-18 X 1/2
