# = Fast-moving Parts 7 09/02
* = Non-Illustrated Parts
FFC13C4AW2, FFC15C4AW2 Publication No.
5995378535
SYSTEM
A = FFC13C4A (FFC13C4AW2)
B = FFC15C4A (FFC15C4AW2)
POS. NO PART NO DESCRIPTION
1 5303925238 A B Condenser
4 216634500 A B Drier-filter
5 216806900 A B Harness-main
22 216056400 A B Clip,compressor mtg ,SPRING
27 5308002681 A B Grommet,compressor
28 5303212615 A B Support,compressor
29 # 216856700 A B Compressor,w/o electricals
30 216649319 A B Controller
32 216694500 A B Clip,controller
42 216232700 A B Washer,flat ,1"OD x 0.531"ID
47 216629600 A B Screw,hex washer head ,10-16 x 0.500 ,tapping
55 # 218909901 A B Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad
85 216533500 - B Wire,ground
86 216036600 A B Screw,ph washer head ,8-32CA x 0.500 ,thread forming
* 5303212614 A B Clip,harness mount
