# = Fast-moving Parts 5 04/03
* = Non-Illustrated Parts
FFU17FC5CW0 Publication No.
5995389433
POS. NO PART NO DESCRIPTION
3 216503100 Screen-drain
5 # 216325600 Fan Blade
6 216604200 Breaker Kit w/corners
7 216603700 Breaker Kit w/corners,lock catch
9 216603300 Breaker Kit w/corners,32" ,top or bottom
13 216822500 Motor,evaporator fan ,115 V
14 216822900 Switch,light/lamp ,ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket,light/lamp ,25 W
18 216707200 Knob,temp control
19 216204900 Gasket,evap cover
20 216230300 Cover,temp control
21 216715200 Control-temperature
22 216823500 Clamp,cap tube ,cold control
22A 5303916855 Tube,sensor sleeve ,plastic ,clear
24 5300052943 Screw-clamp,truss hd cr ,control
25 216820200 Cover-evaporator
26 216503300 Ramp,door closer
27 5303205738 Screw,hinge mtg ,10 (A) x 0.875 ,btm
28 216247400 Hinge,bottom
29 216313500 Hose-drain
32 5308005500 Drain
34 216816200 Shield-light
38 216808900 Hinge,plate ,top
39 5303294372 Nut-insert,1/4-20 UNC ,hinge
40 216809000 Cover-hinge
41 216850900 Screw,hex washer hd ,1/4 x 7/8 ,hinge mtg
42 216458400 Shelf,14.50x27.88
42A 216458200 Shelf,12.50x27.88 ,white
* 216502400 Grommet-shelf mtg
47 216661600 Plate,baffle ,snap fit
50 216394000 Bracket,fan motor mount
59 216372800 Basket,(2)
60 5303212693 Slide-basket
63 216396900 Screw,leveling foot ,plastic ,adjustable
69 5305878546 Bumper-basket
71A 5304416289 Screw,ph truss head ,8-18AB x 0.47 ,EVAP PANEL
79 3017666 Nut-insert
80 06594601 Bracket,control
93 5303161215 Screw,ph truss head ,8-18AB x 0.500
93A 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
93B 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming
101 216835200 Top Hinge Kit
132 5303283898 Screw,6-20AB x 3/8
* 09948773 Insulation,drain tube
* 216795405 Energy Guide
CABINET
