Frigidaire FPRH19D7LF - TRIMKITEZ2 Trim Kit Dimensions; Before You Begin

INSTRUCTION SHEET
©2011 Electrolux Home Products, Inc. Instruction Sheet 297403800 Rev. C 07.18.11
66.00 ± .032
(1676.4 ± .8mm)
25.25”
(641mm)
79.00 ± .06”
(2006.5 ± 1.5mm)
66.00 ± .032
(1676.4 ± .8mm)
75.00 ± .06”
(1905 mm)
25.25”
min.
(641mm)
”
min.
67.12”
(1705 mm)
67.12”
(1705 mm)
75.09”
(1907 mm)
79.09”
(2009 mm)
TRIMKITEZ2 (Part# 297333600) Trim Kit Dimensions
Safety: Always wear safety glasses when using power tools.
Tools Needed:
• Phillips
TM
Screwdriver • Adjustable Wrench to t 1-1/4” • Step Ladder
• Flathead Screwdriver • 3/8” Socket Wrench • Tape Measure (min. 7” length)
• Safety Glasses • 7/16” Socket Wrench • Drill & 1/8” Bit
Before You Begin
• Be careful when unpacking components. Do not use sharp objects when removing packaging material. This may
scratch the surface of trim components.
• Use extreme care when handling the metal trim pieces. Corners are very sharp and easily damaged if dropped.
