# = Fast-moving Parts 11 02/02
* = Non-Illustrated Parts
FRS23W3A Publication No.
5995366761
A = FRS23W3A (FRS23W3AQ3)
B = FRS23W3A (FRS23W3AQ4)
C = FRS23W3A (FRS23W3AQ5)
D = FRS23W3A (FRS23W3AW3)
E = FRS23W3A (FRS23W3AW4)
F = FRS23W3A (FRS23W3AW5)
POS. NO PART NO DESCRIPTION
5 # 5308000010 A B C D E F Fan Blade,red ,evaporator fan
8 5300157666 A B C D E F Bushing-motor mtg,(2)
9 5303292396 A B C D E F Bracket-motor mtg,front
13 # 240315803 A B C D E F Motor-evap fan
13* 215474201 A B C D E F Washer,"slinger" ,nylon ,evap fan shaft
14 5303292397 A B C D E F Bracket-motor mtg,rear
15 240436701 A B C D E F Light Bulb/Lamp, A-15,40 W,120 V, miniature
16 218906801 A B C D E F Socket-light/lamp
17 240374002 A B C D E F Box-control,front
17* 240439901 A B C D E F Wiring Harness,controls
18 240360801 A B C D E F Knob-control
21 240375902 A B C D E F Control-temperature,refr section
21A 5304421067 A B C D E F Control-temperature,frzr section
22 218660702 A B C D E F Tube-insulator
23 # 240375803 A B C D E F Control-defrost, adaptive timer, PC board
23* 5303001259 A B C D E F Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
45 5303001343 A B C D E F Screw,hex washer head ,8-15A x 0.500
53 240369501 A B C D E F Box-control
81 5308016566 A B C D E F Screw,hex washer hd, 8-15A x 0.625, low profile
115 240521101 A B C D E F Damper Assy,w/seal
115* 5304421593 A B C D E F Switch-micro, single pole, dble throw, damper assy
149 240331601 A B C D E F Shroud-fan orfice
* 3205266 A B C D E F Edge Protector,wiring harness
CONTROLS
