Frigidaire FRS23W3A - Page 13

# = Fast-moving Parts 13 02/02
* = Non-Illustrated Parts
FRS23W3A Publication No.
5995366761
A = FRS23W3A (FRS23W3AQ3)
B = FRS23W3A (FRS23W3AQ4)
C = FRS23W3A (FRS23W3AQ5)
D = FRS23W3A (FRS23W3AW3)
E = FRS23W3A (FRS23W3AW4)
F = FRS23W3A (FRS23W3AW5)
POS. NO PART NO DESCRIPTION
1 240333602 A B C D E F Condenser
3 218679606 A B C D E F Block-evap coil,styrofoam ,(2)
4 # 218944001 A B C D E F Drier-filter,R134a System
6 240346402 A B C D E F Harness-wiring,machine compt
6* 240315901 A B - D E - Harness-wiring
6* 240449602 - - C - - F Harness-wiring
6* # 240439901 A B C D E F Wiring Harness,controls
14 5303918253 A B C D E F Defrost Heater Kit
15 # 5303918211 A - - D - - Evaporator Kit
15 # 5303918271 - B C - E F Evaporator Kit
16 5308000110 A B C D E F Strap-evap/heater,aluminum ,(2)
21 5303918214 A B C D E F Thermostat-defrost,kit
22 240330002 A B C D E F Plate-compr mtg
23 218513300 A B C D E F Grommet-compr mtg,(4)
25 240491501 A B C D E F Screw-compressor mtg,1/4-28 x 1.16,shoulder,typ CF
26 240332602 A B C D E F Pan-defrost drain
29 # 5303918251 A B C D E F Compressor,w/electricals
30 # 218721119 A B C D E F Starter-PTC
32 218973501 A B C D E F Clamp,elec cont mtg ,compressor
34 240405201 A B C D E F Grommet,rubber ,black ,cond tube/wire
41 218897001 A B C D E F Screw,hex washer head ,8-32 x 1/4
41* 5308000039 A B C D E F Screw, hex wshr hd,8-32CA x 0.500, serrated head
44 215174700 A B C D E F Clamp-service cord, strain relief, galv steel
45 5308016566 A B C D E F Screw, hex washer hd, 8-15A x 0.625, low profile
55 # 216787800 A B C D E F Capacitor-run
57 240403601 A B C D E F Clip-wiring harness
58 215004600 A B C D E F Screw,hx wshr hd,8-36 x 7/16, cond fan motor,(2)
59 240315501 A B C D E F Shroud-cond fan
59* 240346701 A B C D E F Tape-foam seal,shroud
59* 240359401 A B C D E F Screw-fan shroud,(2)
59A 240346501 A B C D E F Bracket-support,cond mtr ,(3)
59B 240346601 A B C D E F Grommet-bracket,(3)
60 # 240334004 A B - D E - Motor-condenser fan
60 # 240334001 - - C - - F Motor,condenser fan
61 # 240315401 A B C D E F Fan Blade,galv steel ,condenser fan
61A 215004700 A B C D E F Nut,speed
61B 215004800 A B C D E F Grommet-silencer
62 240429401 A B C D E F Trough-drain
70 218990801 A B C D E F Bracket-evap/cvr mtg
72 218397000 A B C D E F Button-handle mtg, dovetail
82 5304418225 A B C D E F Roller, compressor base, rear, (2)
83 5303316859 A B C D E F Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 5304421068 A B C D E F Tube-drain,lower
85 240346201 A B C D E F Tube-connector,suction
86 240409302 A B C D E F Spacer-cond tube,black
* # 5303918213 A B C D E F Heat Exchanger Kit,suction line
* 5303918222 A B C D E F Hot Tube Repair Kit,Service
SYSTEM
