# = Fast-moving Parts 15 02/02
* = Non-Illustrated Parts
FRS23W3A Publication No.
5995366761
A = FRS23W3A (FRS23W3AQ3)
B = FRS23W3A (FRS23W3AQ4)
C = FRS23W3A (FRS23W3AQ5)
D = FRS23W3A (FRS23W3AW3)
E = FRS23W3A (FRS23W3AW4)
F = FRS23W3A (FRS23W3AW5)
POS. NO PART NO DESCRIPTION
1 218976405 A - - D - - Tube-water inlet
1 218976410 - B - - E - Tube-water inlet
1 218976409 - - C - - F Tube-water
1* 218976901 A B C D E F Tube-water inlet,inlet valve to ice maker
4 240351802 A B C - - - Cover-module, bisque
4 240351801 - - - D E F Cover-module, white
8 5304422144 A B C - - - Module-dispenser, bisque
8 5304421823 - - - D E F Module-dispenser, white
10 5304421626 A B C D E F Spring-torsion
14 240323909 A B C - - - Label-module cover,bisque
14 240323908 - - - D E F Label-module cover,white
17 5304421619 A B C D E F Screw
23 240323602 A B C - - - Drip Tray,bisque
23 240323601 - - - D E F Drip Tray,white
24 5304422027 A B C - - - Actuator-water,bisque
24 5304421825 - - - D E F Actuator-water,white
24A 5304422028 A B C - - - Actuator-ice,bisque
24A 5304421826 - - - D E F Actuator-ice,white
30 5304421628 A B C D E F Door Assy-ice chute
30A 5304421624 A B C D E F Door center
30B 5304421625 A B C D E F Insulation-door
30C 5304421629 A B C D E F Door seal
35 5304421620 A B C D E F Damper-rotary
38A# 5304421617 A B C D E F Switch-micro, single pole, double throw
39 5304421627 A B C D E F Pin-hinge
41 5304421829 A B C D E F Spring-actuator
43 215296300 A B C D E F Screw,plask h/l ,#6 x 3/8
56 5304421830 A B C D E F Screw-micro switch,pan head
87 5304421622 A B C D E F Bearing Plate
87A 5304421621 A B C D E F Bearing Plate
* 5303918256 A B C D E F Dispenser heater kit
* 215781700 A B C D E F Clip-tube
DISPENSER
