# = Fast-moving Parts 19 02/02
* = Non-Illustrated Parts
FRS23W3A Publication No.
5995366761
A = FRS23W3A (FRS23W3AQ3)
B = FRS23W3A (FRS23W3AQ4)
C = FRS23W3A (FRS23W3AQ5)
D = FRS23W3A (FRS23W3AW3)
E = FRS23W3A (FRS23W3AW4)
F = FRS23W3A (FRS23W3AW5)
POS. NO PART NO DESCRIPTION
1 218976405 A - - D - - Tube-water inlet
1 218976410 - B - - E - Tube-water inlet
1 218976409 - - C - - F Tube-water
1* 218976901 A B C D E F Tube-water inlet,inlet valve to ice maker
2 5304420650 A B C D E F Spring,shut-off arm
3 3206299 A B C D E F Label,ID plate
4 3206301 A B C D E F Gear
5 3206303 A B C D E F Plate-mounting
6 3206305 A B C D E F Screw-ground wire,8-32 x 0.250
7 # 3206306 A B C D E F Motor-ice maker
8 3206312 A B C D E F Spacer-hold switch
9 3206313 A B C D E F Cam
10 3206315 A B C D E F Clamp
11 # 3206319 A B C D E F Thermal Cutoff, ice maker, complete assy
12 # 240352601 A B C D E F Wiring Harness, ice maker, internal, w/plug
13 # 3206322 A B C D E F Thermostat Assy,ice maker
14 5304420652 A B C D E F Screw,4 x 0.750 ,switch mtg.
15 # 3206324 A B C D E F Switch,(3)
16 5304420653 A B C D E F Support,phenolic
17 # 5303320545 A B C D E F Mold-ice maker,Radius Cube ,with heater
18 3206328 A B C D E F Ejector-ice
19 3206330 A B C D E F Bearing & Inlet
20 5304408581 A B C D E F Screw,8-32 x 0.375
21 3206332 A B C D E F Ice Stripper
22 3206333 A B C D E F Shut-off Arm
23 5304408582 A B C D E F Screw,8-32 x 0.875 ,mold-to-support, (3)
24 3206335 A B C D E F Lever Arm
25 3206336 A B C D E F Screw, 8-18 x 0.562, lever arm/sprt
26 5304420654 A B C D E F Screw-thermo/sprt, 4-24 x 0.375 ,(4)
27 3206338 A B C D E F Screw, 4-40 x 1.000, hold switch mtg, (2)
28 3206339 A B C D E F Screw-timing stop,4-40 x 0.375
29 3206323 A B C D E F Screw,4-24 x 0.750 ,(6)
30 3206341 A B C D E F Screw-timing adj,8-32 x 1.000
31 3206342 A B C D E F Insulator
32 3206343 A B C D E F Plate-valve switch
33 5304408583 A B C D E F Spring-timing adj
34 5304420655 A B C D E F Screw,plazscrew ,8-10 ,(3)
35 5304408585 A B C D E F Screw
36 3206347 A B C D E F Cover-ice maker
42 218515402 A B C D E F Clip,(2) ,tube mtg.
42* 5303001199 A B C D E F Clamp-wiring harness,strain relief, galv steel
45 5303001343 A B C D E F Screw,hex washer head ,8-15A x 0.500
46 5303001193 A B C D E F Clamp,.50 ID ,steel ,water tube
51 240387101 A B C D E F Tube-water,ice mold fill ,extension
55 # 240374501 A B C D E F Valve-water,dual solenoid ,115 V
55* 218873001 A B C D E F • Cap-water valve
60 5303207328 A B C D E F Screw,hex washer head ,8-15A x 1.000, (2)
61 218721500 A B C D E F Bracket-leveling,ice maker
62 218737900 A B C D E F Screw-IM brkt mtg,hex washer head, 8-32D x 0.375
64 5303001549 A B C D E F Clamp,0.31 ID ,steel ,copper wtr line
* 218888001 A B C D E F Adapter-water supply, nut & sleeve, compression ftg
* 240352403 A B - D E - Ice Maker,Radius Cube, 115 V, no instl parts
* 240352407 - - C - - F Ice Maker,Radius Cube, 115 V, no instl parts
ICE MAKER
